Filling line for CSD in PET bottles with capacity 14 000 bph for 1.5 L and 2.0 L. ALSIM
Продано
SKU: 14102019
Filling line for CSD in PET bottles with capacity 14 000 bph for 1.5 L and 2.0 L.
Line is in a perfect working condition and still in operation. On request we can arrange line inspection on requested time and date.
Output of the line is 14 000 PET bottles per hour, based on the formats: 1,5 liters, and 2,0-liter PET as a main set, with specified PCO 1881 short neck with 28 mm diameter.
Техническая информация
- Line capacity: 14 000 bph for 1.5 liter, 14 000 bph for 2.0 liter
- Bottle sizes: 1.5 liter / 2.0-liter PET
- Status of the line: Still in operation until January 2020
- Used for filling: CSD
- Cap type: PCO 28 mm (1881 Short neck)
- Packages: Dusseldorf Euro pallet with tray, Euro palette with tray
- Conditions: Good, regularly serviced
Blow molding machine:
- Manufacturer: SIDEL
- Type: SBO 10 Four
- Manufacturing year: 2000
- Bottle formats: 1.5 L – 2 L
- Forms included: Yes (1.5 L and 2 L)
- Other remarks: Chiller included, preforms hopper and feeder included
Rinser – Filler – Capper:
- Manufacturer: SIDEL – ALSIM
- Type: RV-P70
- Year: 2000
- Bottle formats: 1.5L / 2 L
- Number of filling positions: 48
- Number of filling valves: 70
- Number of capping heads: 10
- Capper: AROL
- Cap type: PCO 28 mm (1881 Short neck)
Mixer:
- Manufacturer: MORÁVEK
- Type: MIX 24G
- Year: 2000
- Capacity: 28 000 L / hour
Labeling machine:
- Manufacturer: KRONES
- Type: CONTIROLL 600-15
- Year: 2004
- Number of labeling stations: 1 station, Hot Melt
- Label material: OPP from roll
- Label positions: Wrap around
Date coder:
- Manufacturer: VIDEOJET
- Type: 1520
- Year: 2015
Shrink wrapper:
- Manufacturer: SMI
- Type: SK 450F
- Year: 2006
- Try possibility: No
- Format: 2×3
Carry handle applicator:
- Manufacturer: CEFMA
- Type: CH120
- Year: 2005
Palletizer:
- Manufacturer: CERMEX
- Type: P421.20
- Year: 2000
- Pallet dimensions: Euro standard (1200 x 800 mm), Dusseldorf (600 x 800 mm)
Pallet wrapper:
- Manufacturer: ROBOPACK
- Type: Helix HS30
- Year: 2000
Conveyor systems:
- Air conveyors: approx. 90 m.
- Bottle conveyors: approx. 50 m.
- Pack conveyors: approx. 30 m.
